PCBA Inquiry | Request a PCB Assembly Quote
REGULUS reviews your PCBA project requirements and RFQ files to prepare a PCB assembly quote for high-mix, standard, prototype, or production builds. Please provide the applicable BOM, Gerber files, assembly data, drawings, quantities, and programming or testing requirements so our team can review the manufacturing scope, key technical requirements, and estimated lead time.
PCBA Manufacturing Scope for Quote Review
PCB assembly quote review can cover the applicable manufacturing, programming, inspection, and testing requirements defined in your RFQ package. Relevant capabilities include:
-
Manufacturability Review: At the RFQ stage, we review available project files for key manufacturability concerns and clarification items. Formal DFM / DFT review is performed after order confirmation where applicable.
-
SMT Assembly: Surface Mount Technology (SMT) assembly supports high-density components, miniature packages, and other applicable surface-mount designs.
-
THT & DIP Assembly: Through-hole and DIP assembly are available for components and designs requiring through-hole insertion and soldering.
-
IC Programming: Firmware programming can be included when the required firmware files, programming instructions, device information, and applicable acceptance requirements are provided.
-
Inspection & Testing: 100% AOI is applied to SMT and THT assemblies. X-ray inspection is used for BGA where applicable, while functional testing can be performed according to defined procedures, fixtures, and acceptance criteria.
-
Turnkey PCB Assembly: PCB fabrication, component sourcing, and PCB assembly can be combined within a turnkey manufacturing scope according to project requirements.
PCB Assembly Inquiry Checklist and Required RFQ Files
For PCB assembly quote review, please complete the Product Survey and provide the applicable RFQ files listed below. Core quotation files typically include the BOM, Gerber files, Pick & Place data, assembly drawing, PCB Requirements, and required quantities. Programming, testing, conformal coating, inspection, and packing documents should be included where applicable to your project scope.
Please email the files to sales@reguluspec.com or provide a downloadable link for larger RFQ packages.
#
List of Documentation
Comments
Download
3
SMD/DIP assembly drawing
PCB assembly drawing in *.cad or *.pdf formats
5
Gerber files
provide the PCB Gerber files by email or a downloadable link
6
Conformal coating drawings, including: material requirements; tolerances; units (metric/imperial); standard compliance
drawings in *.cad or *.pdf or any other suitable for your formats
7
Programming/Tuning/Testing software
when testing and tuning is required
8
Firmware
when testing and tuning is required
9
Programming/Tuning/Testing instructions (SOP)
when testing and tuning is required
10
Inspection instructions
in *.pdf or any other suitable for your formats
11
Principal (schematic) drawing
for debugging purposes
12
Sample for OQC report
optional, otherwise will be provided in Regulus format
13
Packing specifications and drawings
drawing in *.cad or *.pdf formats
PCBA Quote and Order Process
After the required RFQ files and project requirements are received, the project proceeds through quotation, order confirmation, engineering review, production preparation, assembly, inspection and testing, and shipment.
Step 1: RFQ Review
Submit the BOM, Gerber files, Pick & Place data, assembly drawings, quantities, and applicable programming or testing requirements for initial technical and sourcing review.
Step 2: Quotation
We prepare the PCB assembly quotation and estimated lead time based on the defined manufacturing scope, material requirements, quantities, and applicable programming or testing requirements.
Step 3: Order Confirmation & DFM/DFT Review
After order confirmation, the project proceeds to formal DFM / DFT review where applicable. Manufacturing, assembly, testability, and clarification items are reviewed before production preparation.
Step 4: Production Preparation & Tooling
Production data and required tooling are prepared, including SMT stencils, soldering pallets, programming or testing fixtures, and other project-specific production aids where required.
Step 5: PCBA Production
PCB assembly proceeds according to the approved production data and project scope, including applicable SMT, THT / DIP, and programming processes.
Step 6: Quality Control & Testing
100% AOI is applied to SMT and THT assemblies. BGA assemblies receive X-ray inspection where applicable, and defined functional testing is performed according to the agreed test scope and acceptance criteria.
Step 7: Packaging & Delivery
Completed assemblies are packaged according to the agreed packing requirements and prepared for shipment to the specified destination.
Submit Your PCBA RFQ for Quote Review
Ready to request a PCB assembly quote? Send your completed Product Survey and applicable RFQ files to sales@reguluspec.com. We will review the submitted manufacturing requirements and confirm any technical or documentation questions before preparing the quotation and estimated lead time.
